Self-priming pump for sewage (51m3/h max)
- Exhaust pump which allows large quantities of loaded water to be moved.
- Can be used in several areas such as construction sites or mines.
- Aluminum flanged suction and discharge ports, easily replaceable.
- Marine option with bronze impeller.
- Made in Europe.
performances
- Diesel, gasoline or electric engine
- Max flow: 51m3 / h - 850 lpm
- 500 lpm at 1.7 bar
Further information
Engine characteristics
- Engine: Electric, Diesel (Hatz / Lombardini) or Gasoline (Honda / Briggs / Lombardini / Robin)
- Starter: Manual or electric
Pump characteristics
- Self-priming centrifugal pump for very heavy water suitable for construction sites, mines and sea water.
- Cast iron wear plate, easily removable, coated with abrasion and grease resistant rubber.
- Fittings: BSP 2 ”
- GALSI 5 UNI 3600 aluminum pump body
- G25 cast iron impeller
- Max flow: 51m3 / h - 850 lpm
- Max pressure: 3 bar - 30m
- Priming: Automatic by filling the pump body
- Solid passage: 28mm
Assembly of the motor pump
- Configuration: Protective frame or chassis on wheels with 4 handles
- Removable pump body
- Priming plug
- Dimensions: 775 x 440 x 590 mm (chassis excluding trolley)
- Weight: 30kg
Navy option
- Pump body in UNI 3054 aluminum resistant to salt water
- Cast iron volute G25
- Bronze impeller bral UNI5275
